| 厚度 Thickness (micron(u)) |
Yield (m2/Kg) |
長 度 Length (m/roll) |
300直徑Diameter (mm/3吋IDcore) |
| 15 | 73.26 | 4000 | 300 |
| 20 | 54.95 | 4000 | 340 |
| 25 | 44.96 | 4000 | 380 |
| 30 | 36.33 | 4000 | 410 |
| 40 | 27.47 | 2000 | 340 |
| 50 | 21.98 | 2000 | 380 |
| 60 | 18.32 | 2000 | 410 |
| 70 | --- | 1500 | --- |
| 上表為實驗室數據.僅供參考用 | |||
| 悟性項目 Physical Properties | 比重 |
拉力強度 |
伸長率 |
霧度 | 光澤度 | 加熱收縮 |
熱封溫度 |
摩擦係數 |
| 單位 Unit | --- | Kg/cm2 | % | % | % | % | ℃ | --- |
| 測試方法 Tesemethod | ASTM D1505 | ASTM D882 | ASTM D882 | ASTM D1003 | ASTM D2475 | 100℃(oven) 60min |
32psi 0.7sec | ASTM D1894 |
| 樣品方向 Sample direcyion | --- | MD | TD | MD | TD | --- | --- | MD |
| 單層BOPP膠膜 Single Layer BOPP Film |
0.91 | 1000、2000 | 230、80 | 3.0 | 130 | <4、TD | --- | --- |
| 二層與三層共可壓出BOPP膠膜 2-Layer & 3-Layer Co-extruded BOPP film |
0.72—0.91 | 600、1500 | 220、70 | 30 | 120 | <3.5、<2 | --- | --- |
